Milano Compact - Type 11 Single Panel Radiator - 400mm x 600mm

Product Code

MC1140060

Be the first to review this product

£23.95

inc VAT

Free Delivery

Out of stock

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Milano Compact - Type 11 Single Panel Radiator - 400mm x 600mm

Details

Revamp any room in your home with the Milano Compact type 11 400mm x 600mm single panel radiator. Featuring a high quality white powder coated finish that will complement any décor, this radiator produces a superb heat output to ensure your room feels warm and inviting in no time.

Compact Type 11 Single Panel Convector Radiator Features:

400mm x 600mm x 50.22mm
1,750 BTUs (513 Watts)
White powder coat finish
10 year guarantee
Tested and Certified BS EN 442 Standards
CE Marked
Includes Wall fixings, Wall plugs, Blanking and Bleed plug

Determine your room's heating requirements with our BTU Calculator

Calculate the required BTU output of your room

Room Dimensions

Metric (metres) Imperial (feet)

Width (m) *

Height (m) *

Length (m) *

Window Area X² (Calculate this by multiplying window height by window length): *

Room Information

Type of room: *

Where are you heating?

What is below the room? *

Think about the flooring of your room, and whether there is another room below

What is above the room? *

Where applicable, choose the amount of insulation

Select type of outside wall: *

This helps us calculate how much heat the room might lose

Select type of window: *

This also helps us determine the expected heat loss in the space

Select number of outside walls: *

Reset

Your Requirements

BTU's Required

Watts Required

View suitable products >>

Valves not included - Which Valves do I need?

More Info

More Information
Range	Eco
Orientation	Horizontal
Style	Modern
Category	Standard Panel Convector
Colour	White
RAL Code	9016
Installation Type	Central Heating
Material	Steel
Floor to Centre of Tapping (mm)	Min. 300
Pipe Centres (mm)	690 (approx.)
Wall to Centre Tapping (mm)	37/50
Volume (litres)	1.2
Inlet Connection	1/2"
Maximum Water Pressure	10 Bar
BTU at Delta T30	646
BTU at Delta T50	1248
BTU at Delta T65	1750
Watts at Delta T30	189
Watts at Delta T50	366
Watts at Delta T65	513
Included	Fixing Pack, Vent and Bleeding Plug
Height (mm)	400
Width (mm)	600
Depth (mm)	50
Projection from Wall (mm)	73/86
Weight (kg)	7.19
Certification	CE, EN442
Guarantee	10 Years

Full Description

Update the look and feel of any room in your home with this beautifully compact and simply stylish type 11 single panel convector radiator from Milano. Made from mild steel and featuring a high quality white powder coat finish, this compact convector radiator features an impressive BTU output that guarantees your room will be warm and cosy in no time.

Please note: Outputs are stated at delta T30, T50 and T65. Additionally, valves are not included with these items, but can be purchased separately.

Guides

Type 11 Single Panel Radiator

Top Tip

Not all Radiators are created equally

Check the Certification

This radiator is tested and certified to EN442 standards, meaning we can guarantee the quality and performance of this product. Ensure you check the 'Declaration of Performance' certificates as proof of quality.

Check the Steel Thickness

At BestHeating, we only use select designer brands that use 1.5mm premium gauge steel to ensure superior durability and years of reliable use, without holes or leaks developing.

Check the Weight

Poor steel thickness indicates an inferior radiator. Many lesser products withhold this information, so check the weight. Steel radiators weighing less than others often use 1.2mm steel, which can be dangerous and struggle to cope with high pressure UK systems.

Check the Guarantee

A company that has confidence in its product will offer a longer guarantee than those that don't. Use the length of guarantee as an indicator of quality!
